UN-GJ-DC24-2835-48-16-940-1616-ZC-T301-IP65

Professional secondary optical processing,multiple lens,concentrated light for wall-washing & accent lighting scenario;
3D bend to be perfectly suitable for columns curved architectonic surfaces without any shadows or dark areas;
A wide variety of installation accessories for applications.

规格参数

Led Type:

SMD2835
Lens Angle:

30°、45*60°
Led/M:

48
Bending Direction:

3D
Color:

Static color-white
Power per meter:

16W
Control Mode:

Swtich/Dimming
Working temperature:

-20°C-45°C
Voltage:

DC24V
Lumens output：

2700K

1155lm/M
3000K

1304lm/M
4000K

1402lm/M
6000K

1320lm/M

光分布

AVERAGE BEAM ANGLE(50%):33.4DEC

资料下载

UN-GJ-DC24-2835-48-16-9xx-1616-ZC-T301-IP65

UN-GJ-DC24-2835-48-16-940-ZC-1616-T301-IP65-EN

UN-GJ-DC24-2835-48-16-940-ZC-1616-T301-IP65.ies
