UN-DMX-DC24-5050RGBW-36D6T-18-940-W16-T302

首页产品中心 Flexible Wall-washer

UN-DMX-DC24-5050RGBW-36D6T-18-940-W16-T302

High luminous efficiency LED professional optical lens;
A wide range of lens angle 45 °*60 ° to achieve long-distance washing light;
Exquisite appearance, a variety of accessories, easy quick installation;
DMX512 , 6 pixels/meter;
5 years warranty, lifespan > 50000Hours

规格参数

Led Type:

SMD5050
Lens Angle:

25*45°、30°、60°
Led/M:

36
Bending Direction:

Top bend
Color:

Pixel chasing
Power per meter:

18W
Control Mode:

DMX
Working temperature:

-20°C-45°C
Voltage:

DC24V
Lumens output：

2700K

322lm/M
3000K

352lm/M
4000K

382lm/M
6000K

365lm/M
R

132lm/M
G

351lm/M
B

116lm/M
RGBW

-

光分布

AVERAGE BEAM ANGLE(50%):33.4DEC

资料下载

UN-DMX-DC24-5050RGBW-36D6T-18-9xx-W16-T302

UN-DMX-DC210-5050RGBW-36D6H-18-940-W16-T302-UD-All colors light-up-EN

UN-DMX-DC210-5050RGBW-36D6H-18-940-W16-T302-UD-All colors light-up.ies
